アキシアルアンギュラころ軸受 AXSシリーズ

BMT ベアリングのアキシャルアンギュラころ軸受 AXS シリーズは、高いアキシアル剛性、安定した回転精度、およびアキシアル荷重とラジアル荷重の複合荷重下での信頼できる性能を必要とする機器向けに設計されています。 20 年以上のベアリング製造経験に基づいて設計された当社の AXS シリーズは、機械製造業者が高速産業用途で動作安定性を向上させ、振動を低減し、耐用年数を延長するのに役立ちます。中国の専門ベアリングメーカーとして、BMT Bearings は、世界中の精密機械、自動化機器、工作機械、高耐久トランスミッションシステム向けにカスタマイズされた AXS ベアリングソリューションを提供しています。

お問い合わせを送信

評価: 5.0

(評価数: 1)

製品説明

Our Axial-angular Contact Roller Bearings AXS Series combine the advantages of axial load capacity and angular contact design, enabling the bearings to achieve higher stiffness, better rotational accuracy, and more stable load distribution during operation. In practical applications, this design effectively reduces vibration, operating noise, and premature wear caused by unstable load transmission.

Axial Angular Contact Roller Bearings Axs Series

Technical Parameters

Angular contact roller bearings AXS series
Related bearing models	Mass m	Dimensions				Contact angle	Centring of the bearing rings				Basic load ratings
	=g	d	D	H	Tolerance	a(°)	on the shaft da	Tolerance	in the housing Da	Tolerance	dyn. Ca N	stat.C0a N	dyn. Cr N	stat.C0r N
AXS0816	3	8	16	3	+0.26 to +0.06	45	8	-0.15 to 0.05	16.3	+0.05 to +0.15	3, 600	6, 300	1, 510	1, 270
AXS1220	3	12	20	3	–0.24 to –0.44	60	12.2	-0.15 to 0.05	20.2	+0.05 to +0.15	3, 400	7, 800	–	–
AXS2034	16	20	34	5	–0.1 to –0.2	60	20.2	-0.15 to 0.05	34.2	+0.05 to +0.15	9, 800	25, 000	–	–
AXS3550	27	35	50	6	–0.1 to –0.3	60	35.2	-0.2 to -0.1	49.2	+0.1 to +0.2	18, 200	52, 000	–	–
AXS4558	35	45	58	6	–0.1 to –0.3	45	45	-0.2 to -0.1	58	+0.1 to +0.2	18, 200	56, 000	7, 600	11, 200
AXS6074	36	60	74	5	-0.6 to 0	60	60	-0.2 to -0.1	74	+0.1 to +0.2	15, 600	62, 000	–	–
AXS8599	60	85	99	6	-0.5 to 0	60	85	-0.2 to -0.1	99	+0.1 to +0.2	26, 500	109, 000	–	–
AXS100115	70	101	115	6	-0.5 to 0	60	101.2	-0.2 to -0.1	114.8	+0.1 to +0.2	30, 500	139, 000	–	–
AXS115129	65	115	129	5	-0.5 to 0	60	115	-0.25 to -0.15	129	+0.15 to +0.25	21, 600	115, 000	–	–
AXS120134	80	120	134	6	-0.5 to 0	60	120	-0.25 to -0.15	134	+0.15 to +0.25	31, 500	152, 000	–	–
AXS140154	90	140	154	6	-0.3 to 0	60	140.2	-0.25 to -0.15	153.8	+0.15 to +0.25	36, 000	190, 000	–	–
AXS145169	267	145	169	7.4	-0.4 to +0.1	45	145	-0.4 to -0.15	169	+0.15 to +0.25	76, 000	400, 000	31, 500	80, 000
AXS150164	100	150	164	6	-0.5 to 0	60	150	-0.25 to -0.15	164	+0.15 to +0.25	35, 500	190, 000	–	–
AXS160180	168	160	180	6	-0.2 to 0	60	160	-0.25 to -0.15	180	+0.15 to +0.25	68, 000	405, 000	–	–
AXS175200	300	175	199	7.4	-0.4 to +0.1	45	175	-0.25 to -0.15	199	+0.15 to +0.25	84, 000	480, 000	34, 500	96, 000

Why Customers Choose BMT Bearings AXS Series

Higher Rigidity Under Combined Loads

The optimized roller and raceway geometry of the Axial-angular Contact Roller Bearings AXS Series allows the bearing to support both axial and radial forces simultaneously. This makes the bearing particularly suitable for equipment operating under dynamic or fluctuating loads.

Stable Accuracy at High Speed

In high-speed applications, bearing stability directly affects machining accuracy and equipment lifespan. Our AXS Series is manufactured with precision grinding processes and strict dimensional control to ensure smooth rotation and consistent positioning accuracy.

Longer Service Life

Through improved internal structure design and optimized contact angles, the AXS Series minimizes friction heat and uneven stress concentration. This helps extend bearing operating life while reducing maintenance frequency.

Low Noise and Smooth Operation

BMT Bearings applies EMQ-level manufacturing standards in selected production lines, improving running smoothness and reducing vibration. This is especially important for precision machinery and automated production systems.

Real Manufacturing Experience Behind the Product

As a bearing manufacturer established in 2004, BMT Bearings has continuously invested in automated grinding production lines, precision testing equipment, and quality management systems. Today, our annual bearing production capacity exceeds 100 million pieces.

Our engineering team has extensive experience supporting customers from industries including:

· Precision machine tools

· Industrial automation systems

· Electric motors

· Gearboxes and reducers

· High-speed transmission equipment

· Packaging machinery

· Pump systems

· Heavy-duty industrial machinery

During actual field cooperation, many OEM customers requested a bearing solution capable of maintaining accuracy under heavy axial loads while also tolerating radial force generated by high-speed rotation. The Axial-angular Contact Roller Bearings AXS Series was developed directly from these real industrial requirements.

Manufacturing and Quality Control

At BMT Bearings, product consistency is verified through strict production and inspection procedures.

Our factory operates with:

· Automatic grinding production lines

· Precision assembly systems

· Complete dimensional inspection processes

· Noise and vibration testing equipment

· Hardness and material verification systems

We are certified under ISO9001 and IATF 16949 quality management systems, ensuring stable product quality for global industrial customers.

Every batch of Axial-angular Contact Roller Bearings AXS Series undergoes inspection before delivery to ensure reliable operating performance.

Customized Bearing Solutions Available

Different equipment requires different structural tolerances, preload conditions, and operating speeds. BMT Bearings supports customized solutions according to customer drawings, working conditions, and application requirements.

We can assist customers with:

· Custom dimensions

· Material selection

· Lubrication optimization

· Sealing solutions

· Precision grade requirements

· OEM branding support

Our engineering team works directly with customers to improve bearing performance in real operating environments rather than offering only standard catalog products.

Global Supply and Technical Support

BMT Bearings products are exported to multiple international markets and widely used by OEM manufacturers and industrial distributors. We understand that industrial buyers value not only product quality, but also stable delivery, technical communication efficiency, and long-term cooperation reliability.

From quotation to after-sales support, our team focuses on providing practical and professional bearing solutions that customers can trust.

BMT Production Workshop

Choose BMT Bearings for Reliable AXS Bearing Performance

The Axial-angular Contact Roller Bearings AXS Series represents BMT Bearings’ long-term manufacturing experience, precision production capability, and continuous focus on solving real industrial problems.

If your equipment requires higher rigidity, improved rotational stability, and dependable performance under combined loads, BMT Bearings can provide a reliable bearing solution tailored to your application.
